Stoddart Plumbing Floor Mounted Mop Cleaners Sink CS.05  Plumbing

Stoddart Plumbing Floor Mounted Mop Cleaners Sink CS.05

$1,089.77 - $1,089.77
$1,089.77
$1,089.77 - $1,089.77
$1,089.77
SKU CS.05

Stoddart CS.05 floor-mounted mop / cleaner sink: 560 × 460 × 800 mm, 44 L bowl, 235 mm depth, 1.5 mm stainless steel shroud, 90 mm basket waste, low grate height and hinged grate for full access.

  • Model: CS.05 (floor mounted mop / cleaner sink)

  • External Dimensions: 560 × 460 × 800 mm

  • Bowl Capacity: 44 L

  • Bowl Depth: 235 mm

  • Shroud Material: 1.5 mm 304 stainless steel, No.4 satin finish

  • Waste Connection: 90 mm basket waste with 50 mm outlet

  • Mounting: Floor mounting via shroud slots; optional bracket support

  • Grate: Welded steel grate with six bars, hinged for access

  • Noise Control: Sound suppression pad under bowl

Apply for Finance
Simply Hospitality Notes
Product Guide
Brand Guide

Stoddart CS.05 Floor-Mounted Mop / Cleaner Sink

The CS.05 Floor-Mounted Mop / Cleaner Sink from Stoddart is built for commercial utility and sanitation areas. Its low grate height reduces heavy lifting, and the durable stainless steel shroud enables it to be securely bolted to the floor. With a 44 L bowl capacity and a 90 mm basket waste, it’s designed for effective mop and bucket cleaning, rinsing, and wash-down tasks.

Key Features

  • Low grate height to minimize heavy lifting by staff
  • 1.5 mm stainless steel shroud, mountable to most floors
  • 90 mm basket waste included (for catching solids)
  • Welded steel grate with six bars to support buckets while filling/draining
  • Highly polished bowl, 235 mm deep, to reduce splashing
  • Hinged grate that lifts for full bowl access
  • Sound suppression pad under bowl base to reduce noise
  • Rolled edges for operator safety
  • Supports optional tapware (WELS / WaterMark approved) — sold separately

Specifications

  • External Dimensions (W × D × H): 560 × 460 × 800 mm :contentReference[oaicite:0]{index=0}
  • Bowl Capacity: 44 L :contentReference[oaicite:1]{index=1}
  • Bowl Depth: 235 mm :contentReference[oaicite:2]{index=2}
  • Shroud Material: 1.5 mm, 304-grade stainless steel, No.4 satin finish :contentReference[oaicite:3]{index=3}
  • Waste Connection: 90 mm basket waste with 50 mm connection :contentReference[oaicite:4]{index=4}
  • Mounting / Fixing: Heavy duty shroud with multiple slots to bolt to floor; bracket for tilt wall mount also supported in some builds :contentReference[oaicite:5]{index=5}
  • Model Code / Notation: CS.05 (floor-mounted mop / cleaner sink) :contentReference[oaicite:6]{index=6}
Stoddart CS.05 Floor-Mounted Mop / Cleaner Sink

  • Product Colour Stainless Steel
  • Product Composition Stainless Steel
  • Model
