How the System Works
AIR.Plus reversing airflow, STEAM.Plus humidity and DRY.Plus extraction support roasting, browning, grilling, frying-style finishes and bakery work under direct manual control. The controls are most effective when recipes are built around a fixed product, tray, load and starting condition, then reviewed against the finished result.
Capacity and Workflow
This configuration accepts 5 trays of GN 1/1. The published tray pitch is 67mm, and the external size is 750 W × 773 D × 772 H mm. Check tray depth, rack movement and loading clearance with the real menu and site layout.
Control and Cooking Technology
- Direct manual control of time, temperature, humidity and two fan speeds
- AIR.Plus multi-fan reversing airflow
- STEAM.Plus on-demand humidity
- DRY.Plus moisture extraction
Construction, Cleaning and Daily Operation
- High-resistance stainless-steel chamber
- Double-glazed door and chamber lighting
- Commercial tray supports
- Manual cleaning with access planned into the daily close-down routine
Plan the cleaning method and close-down time before service starts. Keep door seals, fan areas, tray supports and the chamber free of residue so airflow and heat transfer remain predictable.
Installation Considerations
Its electric heating supports precise control and an all-electric kitchen strategy; confirm the exact voltage, phase, breaker and connection shown for the selected model. Confirm clearances, ventilation and service access against the model drawing before finalising the bench or stand.
Technical Specifications
| Model | XV393 |
| Equipment type | manual GN convection oven with humidity |
| Power source | Electric |
| Capacity | 5 trays GN 1/1 |
| Tray pitch | 67mm |
| Temperature range | 80 °C – 260 °C |
| Control panel | Knob |
| Door | Hinge on the left side |
| Dimensions | 750 W × 773 D × 772 H mm |
| Net weight | 67kg |
| Electrical option 1 | 380-415 V, ~3PH+N+PE, 7.1kW, 11A maximum draw, 16A breaker listed, plug/connection: NOT INCLUDED |
| Electrical option 2 | 220-240 V, ~3PH+PE, 7.1kW, 18A maximum draw, 20A breaker listed, plug/connection: NOT INCLUDED |
| Electrical option 3 | 220-240 V, ~1PH+PE, 7.1kW, 31A maximum draw, 32A breaker listed, plug/connection: NOT INCLUDED |
| Water inlet | 3/4-inch NPT |
| Water pressure | 22 to 87 psi; 1.5 to 6 Bar (29 psi; 2 Bar |
Water Quality and Commissioning
A potable water supply that meets the model specification is essential for reliable steam performance and scale control. Confirm treatment after testing the actual site water. Electrical, gas where applicable, drainage, ventilation and commissioning must be completed by qualified trades to local requirements.
