Blue Seal has long been known for the quality and performance of its commercial deep fryers. The Blue Seal Evolution Series elevates this reputation with a more modern and streamlined design. The entire range of commercial deep fryers is available with either mechanical or digital controls.

Models with digital controls provide precise temperature regulation, three product timers, and a digital display for both time and temperature. Twin pan models feature independent digital controls for each pan and come equipped with six product timers.

Overall Construction

• Full stainless steel construction
• Mounted on two fixed and two swivel castors
• 1/3 HP motor, reversible, heavy duty pump
• Heavy duty motor switch
• Rigid return delivery tube for safe, efficient return of oil and shortening to fryer tank
• Reusable ‘easy clean’ filter bags, with upgrade kit to carbon pad filtering available
• Heavy duty stainless steel handle
• Cord storage
• Heavy duty heat resistant handle fitted to oil delivery tube

Controls

• Off/Forward/Reverse pump control

Cleaning and Servicing

• Open stainless steel pan for easy clean
• Easy clean stainless steel exterior

Specifications

• Pump: 1/3 HP single phase reversible pump
• Electrical requirements:
  • 220 - 240 V.a.c., 50/60 Hz, 1 P+N+E, 3.2A
  • 110 - 120 V.a.c., 50/60 Hz, 1 P+N+E, 6.4A
• Electrical connection:
  • 62mm from RH side, 365mm from rear, and 440mm from floor
  • 3 pin 10A plug cordset fitted
• Filtering capacity: 20 litres
• Fryer compatibility: GT45/E and GT46/E
• Under fryer storage: GT45/E and GT46/E

• Dimension Dimensions Width: 324mm Depth: 683mm Height: 562mm
• Weight
